PRODUCT

ESAMSA 1.2 Mid Drive Baseframe

SUV of electric
Bike
Two-Wheeled
-Front
ESAMSA Steering
System

ESAMSA 1.2 Mid Drive Kids Cargo

The Family Lifestyle
Go Anywhere with
Your Lovely Kids
a Genuine Dutch Style
(Bakfiets, in Dutch)

ESAMSA 1.2 Mid Drive Cargo

Super Fit for
Urban Area
Personal Logistics
Agility with
Torque
Specification
Name of the Main Parts

Specification of Main Parts



Technical Specification, Components and Wear Parts Lists



Technical Specification¹

  • Total Length¹
  • Height¹
  • Width of bike¹ / handlebar
  • Wheelbase
  • Weight¹
  • Max pay load in front
  • Max weight in rear
  • Max saddle height, BB-saddle / ground-saddle
  • Min saddle height, BB-saddle / ground-saddle
  • Frame material
  • 2,115mm
  • 1,180mm
  • 865mm/650mm
  • 1,530mm
  • 33.5kg
  • 125kg
  • 25kg
  • 780mm/1,050mm
  • 640mm/910mm
  • Aluminum 6061-T6

¹based on ESAMSA 1.2 baseframe

Electric Related Components²

  • Type
  • Power
  • Torque
  • Battery
  • Range max(in eco)²
  • Range daily²
  • Front headlight
  • display and on board computer
  • Sensor
  • Charger
  • DAPU MD250 Mid Drive
  • 250w
  • 75nm
  • 417.6wh
  • 80km
  • 40 ~ 50km
  • 36v, LED 10lux
  • DAPU DPLCD-P
  • Speed Sensors & Magnet
  • 36V, 2.0A

²depending on the owner’s driving or managing skills



Components
Name Maker Model Specification
Chain KMC HG-40 116links
Chainwheel front     36teeth
Seatpost Zoom SPS-405 Suspension 27.2mm x 350mm
Saddle Velo VL-8080E
Stem KW G-7-2-2 Folding stem angle 0°, upper length 270mm,
Lower length 265mm
Handlebars Zoom NR-AL-362 Aluminum 650mm
Pedals Wellgo MG2 Aluminum pedals
Shifter cables     4mm x 2,300nn(inner), 1.2mm x 2,380mm(outer)
Wear Parts Lists of Front Wheel
Name Maker Model Specification
Brake Tektro Auriga eTwin HD-E525 Hydraulic dual disc
Brake pads Tektro P20.11 High performance metal ceramic compound
Tires Kenda K905-010 20 x 2.35
Hub   KMBD1701 13G x 28H
Spokes JN   13G(2.3mm) x 171mm
Brake hose dimension Tektro   ⓐ5.5mm x 1,800mm, ⓑ5.5mm x 700mm
Kids Cargo Box ESAMSA ESAMSA1.2 15.7kg, L926mm x W580mm x H524mm
Cargo Rack ESAMSA ESAMSA1.2 11kg, L898mm x W582mm x H160mm(F),
H310mm(R)
Wear Parts Lists of Rear Wheel
Name Maker Model Specification
Brake Tektro Auriga eComp HD-E500 Hydraulic disc
Brake pads Tektro P10.11 Metal ceramic compound
Tires Kenda K905-006 26 x 2.30
Hub   KT-K57R 12G x 36H
Hub spacing     153mm
Spokes left JN   12G x 252mm
Spokes right JN   12G x 250mm
Rear sprocket Shimano CS-HG200-7 Min 12t-Max32t(12-14-16-18-21
-26-32t)
Rear derailleur Shimano Acera RD-N360-SGS 7speed
Brake hose dimension Tektro   5.5mm x 2,000mm


The Story
Salon Du Velo 2020 at Lausanne, Switzerland, July 2020
Salon Du Velo 2020 at Lausanne, Switzerland, July 2020
This is the first and last bike show 2020 in Europe under COVID19 Pandemic.
ESAMSA was only cargo bike manufacturer that participated this show.
The weather was really hot and the visitors seemed pretty worrying about COVID19,
but there were many visitors asking and test riding ESAMSA bikes.
Be careful and heathy.
Velo Frankfurt Das Fahrradfestival 2019, June 2019
Velo Frankfurt Das Fahrradfestival 2019, June 2019
It was a first and an official event that ESAMSA participated in Europe bike show or event. A lot of people visited and had a test riding with bikes for two days.
It was a first and an official event that ESAMSA
participated in Europe bike show or event.
A lot of people visited and had a test riding
with bikes for two days.
The Journey of Europe Cities(6cities, 4 countries), May ~ June 2019
The Journey of Europe Cities(6cities, 4 countries), May ~ June 2019
It took about 10days of meeting
with European dealers that we've
met at The China Cycle 2019.
This journey was a great experience
and we've decided where the HQ should be settled
ADFC Frankfurt 2019, May 2019
ADFC Frankfurt 2019, May 2019
ADFC Frandfurt 2019, which was a local bike festival that ESAMSA participated first time. This event was sort of small but it seemed every participants and visitors were really happy and enjoyed their time with bikes.
ADFC Frandfurt 2019, which was a local bike festival
that ESAMSA participated first time.
This event was sort of small but it
seemed every participants and
visitors were really happy and
enjoyed their time with bikes.
The China Bike Show 2019, April 2019
The China Bike Show 2019, April 2019
The first appearance of ESAMSA 1.2 in
public exhibition and
European dealers were interested on 1.2 with its steering system and the design of kids cargo.
About

ESAMSA was born for and has always been thinking that someday every mankind will trip to other place where

they want or need to be without paying anything, this is what ESAMSA has named as 『FREEDOM of TRIP』

ESAMSA has three philosophies for moving on,

First, produce a decent mobility that everybody can ride it

Second, provide a platform that everybody can connect it

Third, prepare a business structure that everybody can trip with 『FREEDOM of TRIP』

So we have started developing, redesigning and manufacturing the ESAMSA 1.2, it is a Bakfiets(in Dutch),

Two-Wheeled-Front electric bike that grandfather/mother, lady who has never driven a bike before, or even a kid can ride it easily with an electricity.

Now we are developing ESAMSA 1.3(for shared mobility) and 1.4(automobile-like-driving), and 2.0

(Four-Wheeled-Mobility) that will be the ultimate urban mobility for people and urban logistics.

Recently ESAMSA B.V. has settled a new office at Rotterdam, The Netherlands and will do what ESAMSA

has planned for.

Now, this is a time to show Challenges with Courage

Founder and CEO of ESAMSA B.V.
Andrew Suh
